Detailed Product Description
| Type: |
2 WAY Full Range Audio Speaker |
Size: |
15"x1, 3"x1 |
| Packing: |
Carton |
Warranty: |
1 Year Free Warranty |
| Power: |
500watt RMS, 1000watt PEAK |
Cabinet: |
Plywood |
| High Light: |
Night club Audio System, stereo audio systems |
2 Way Audio 15 Inch Pa System Plywood Speaker Box For Night Club
CV-152C/CV-152P is a 2-way, full range loudspeaker system. Its features include one high efficient 15＂woofer and one 3＂titanium compression driver housed in a compact plywood enclosure, combining smooth dynamic full frequency performance with high power driver units. It is particularly suitable for clubs, theaters, halls, discos, conferences, etc. The CV-152P features a highly efficient power amp module.
| Model |
CV-152C & CV-152P(Active) |
| Type |
Two-way, full range system |
| Frequency Response |
50Hz-18kHz±3dB |
| Power handling |
500W(RMS)1000W(PEAK) |
| Power amp |
1000W/8ohm (CV-152P) |
| Amplifier type |
Switching power amp, class
D circuit |
| Sensitivity |
100dB(1W@1M) |
| Max@S.P.L |
127dB(PEAK/1M) |
| LF section |
15"(380mm) woofer 100mm
(4in)coil |
| HF section |
3"compression driver with
75mm titanium diaphragm |
| Nominal impedance |
8 ohm |
| Output section |
2-channel |
| Dispersion pattern |
60°H×40°V |
| Surface finish |
Black paint |
| Speaker cables |
1(+)1(-) |
| Input connectors |
2×NL4MP speakon |
| Dimensions |
432×697.5×430mm(W×H×D) |
| Package dimensions |
502×770×500mm/0.2cbm |
| Enclosure |
Plywood |
| Net weight |
34kg(CV-152C)/35kg(CV-152P) |
| Gross weight |
38kg(CV-152C)/39kg(CV-152P) |
ABOUT US:
CVR PRO-AUDIO is a cutting edge professional sound reinforcement system manufactory in Guangzhou,China.Our products includes: PA speaker system,indoor and outdoor line array speaker system,subwoofers,floor monitors, power amplifiers,microphones and speaker management system.
We provide these products for any sizes events, stadiums, churches, performing arts venues, theatres,conference rooms,meeting halls, live bands and any space where audio system are needed.
for inquiries please contact us.
CVR PRO AUDIO aims to:
Become your most trusted and reliable manufactory
Provide high quality pro sound equipment at realistic prices
Provide outstanding designs together with delicate finished
Provide meticulous and considerate service for clients
See more at: www.cvr-audio.com
