Detailed Product Description
| TYPE: |
CLASS TD POWER CIRCUIT |
MODEL: |
PA-4150 |
| CHANNEL: |
4-CHANNEL |
POWER: |
1500w X 4 (8 Ohm) |
| WARRANTY: |
ONE YEAR FREE WARRANTY |
|
|
| High Light: |
Digital Power Amplifier, Stereo Power Amplifier |
Stereo Switching Power Amplifier 4 Channels Power Digital Audio Amplifier
DESCRIPTION & APPLICATION:
OVERVIEW
PA-Series are new generation high quality, high efficiency SMPS power amplifiers. Standard 2U height and 13kg light weight make it ideal for touring performance and fixed installations. With full protect functions, it adopts a full range of onsemi (formerly Motorola) power output transistors. PA-Series supply low distortion, great signal-to-noise ratio, low consumption, high performance, compact size, light weight, delay circuit for soft start and low in rush current advance the appliance to operate efficiently.
APPLICATIONS
Club installations
Live performances
Theater installations
FEATURE
Light weight
High efficiency
SmaIl size, 2U height
Best performance in LF
Clear and attractive sound
| Model |
PA-4150
|
| 8Ω Stereo Power |
4×1500W |
| 4Ω Stereo Power |
4×2550W
|
| 8Ω Bridged Mono |
2×4500W |
| 4Ω Bridged Mono |
2×6800W |
| Frequency response |
20Hz-25kHz ±0.5dB |
| THD+N(Rated Power,4Ω/KHz)% |
0.1%
|
| Signal Noise Ration(dB) |
110dB |
| Input Sensitivity |
20K Ohm Balanced/10K Ohm Unbalanced |
| Output Connectors |
Speakon Connectors(NEUTRIK) |
| Power Requirement |
200-240V/50-60Hz |
| Input Sensitivity |
1V/1.5V |
| Airframe Dimension |
483×377×88mm |
| Package dimensions |
575×565×145mm |
| Net Weight |
14.5kg |
| Gross weight |
16.5kg |
